Input 100MHz/10MHz, output 10MHz/5MHz (customizable up to 110GHz)
Spurious levels below -80dBc
Residual phase noise:
<-160dBc/Hz at 1kHz offset (10-5);
<-160dBc/Hz at 1kHz offset (100-10)
Additional frequency stability 1s ≤ 5E-14 (100-10)
Customizable other input and output frequencies available.
Input frequency 10MHz, output frequency 10MHz
Phase noise <-135dBc/Hz at 1Hz offset
Frequency Stability ≤1E-14 per second
Customizable other input and output frequencies (maximum output frequency >110GHz) available.
輸入10MHz輸出頻率100MHz（可定制）
附加頻率穩定度優于3E-14/s
附加相位噪聲≤-130dBc/Hz@1Hz，≤-135dBc/Hz@10Hz
輸出頻率可定制
應用領域:設備內信號變換，鎖相環窄帶濾波，時鐘提純等
Input 10MHz, output frequency 100MHz
Frequency stability better than 5E-13 per 1 second
Phase noise ≤-160dBc/Hz at 1kHz offset
Input and output frequencies are customizable
Application areas: signal frequency conversion, Rubidium
clock phase noise enhancement, narrowband phase-locked
filtering, clock signal purification, etc.
Output frequency 1MHz to 1000MHz
Frequency resolution ≤10μHz
Additional frequency stability better than 2E-13/s
Phase noise <-100dBc/Hz at 1Hz
Suitable for AOM, EOM driving, low-noise signal sources, etc.
